Rainwater Collection System
A Rainwater Collection System, or Rainwater Harvesting System, is designed to collect, store, treat, and reuse rainwater.
- Initial Rainwater Pretreatment System: This system eliminates pollutants and debris from the initial rainwater runoff. It typically includes devices such as dirt traps and diversion filters to remove larger particles and contaminants.
- Rainwater Storage System: After the initial pretreatment, the rainwater is stored in a storage system, often consisting of rainwater modules or SMC fiberglass tanks. These systems can store large volumes of water and provide a steady supply for later use.
- Rainwater Purification System: To further improve water quality, the stored rainwater undergoes purification processes such as filtration and disinfection. This removes finer particles, harmful bacteria, and other impurities, ensuring the water is safe for various uses.
- Rainwater Control System: This system monitors and controls the entire rainwater collection process. It ensures that the system operates efficiently and can adjust operations based on real-time data, such as water levels in storage tanks.
- Rainwater Reuse System: The treated rainwater is then distributed for various non-potable uses, including irrigation, landscape watering, car washing, road cleaning, cooling water replenishment, and toilet flushing.
|
Item
|
Value
|
|
Warranty
|
More than 5 years
|
|
After-sale Service
|
Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement
|
|
Project Solution Capability
|
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
|
|
Application
|
Sponge city, roof, garage, parking lot, retaining wall, basement
|
|
Design Style
|
Modern
|
|
Place of Origin
|
Shandong
|
|
Brand Name
|
Best
|
|
Model Number
|
WS23080101
|
|
Type
|
Rainwater harvesting module
|
|
name
|
Rainwater collection modular
|
|
material
|
pp plastic
|
|
color
|
black, white
|
|
application
|
construction waterproofing
|
|
usage
|
roof, garden, parking lot, basement, retaining wall
|
|
thickness
|
custom
|
|
height
|
250 mm, 500 mm
|
|
width
|
500 mm
|
|
length
|
500 mm
|
|
package
|
pallets
|
Rainwater collection systems are widely applicable in various settings, including municipal public roads, plazas, parks, urban residential areas, schools, industrial parks, and factories. They are particularly effective in areas with annual rainfall exceeding 400mm, where the economic benefits of rainwater harvesting are more pronounced.
* Residential homes
* Parking areas and driveways
* Playgrounds
* Sports fields
* Parks and gardens
* Underground Stormwater Management
* Infiltration / Soakway Tank
* Detention / Attenuation Tank
* Rainwater Recycling / Harvesting Tank
* Grass Swales
* Bioretention Basins
* Sport field Drainage
* Channel Drainage
* Road Drainage
* CarPark Stormwater Tanking
* Septic & Leach Drains
* Trench Soakway
* Module for infiltration tank and soakwell
* Infiltration tank module
* Stormwater detention and infiltration module
* Aquasave module
* Rainwater catchment systems
* Potable and Recycled Water Infrastructure
* Detention and Retention Basin Construction
* Construction of Car Parks and Large Paved Areas
* Water reticulation sewerage/wastewater
* Infiltration Tanks
* StormwaterTanks
* Detention Tanks drainage
* Attenuation Tanks harvesting
* Underground Drainage system
Rainwater Collection System Benefits
- Water Conservation: Rainwater harvesting helps conserve municipal water supplies by providing an alternative water source for non-potable uses.
- Environmental Protection: By reducing the volume of stormwater runoff, rainwater collection systems help mitigate urban flooding and protect natural water bodies from pollution.
- Cost Savings: In areas with high water demand or limited water resources, rainwater harvesting can lead to significant cost savings by reducing water bills and eliminating the need for expensive water treatment processes.
- Sustainability: Rainwater harvesting is a sustainable practice that aligns with efforts to reduce water consumption and promote environmental stewardship.
- High-capacity (95% void space) and high-strength.
- Offers HS-20 and HS-25 support for traffic loads with cover depths from 6″ to over 16′.
- Modular design installs easily in most footprints.
- Increased infiltration and ex-filtration.
- Easy-to-transport.
- Lightweight and quick to install.
- Permanent and maintainable storage volume.
- Purchase pre-assembled or easily assemble the system on-site
